Connectivity overview

Connect Mative Cloud LM – Logistics Manager to external hardware — telematics modems, GPS devices, IoT sensors, and third-party data providers.

The Connectivity section manages the integration of physical hardware and external data providers. This includes telematics modems installed in vehicles, GPS and IoT devices, environmental sensors, and the raw data events they produce.

What's in connectivity

Section	Purpose
Telematics	Telematics modems — hardware devices that send GPS, OBD-II, and sensor data from vehicles
Devices	GPS trackers, OBD-II scanners, cameras, and other connected devices
Sensors	Environmental sensors — temperature, humidity, door, pressure, motion
Events	Raw data events received from devices and telematics providers

The connectivity architecture

Data flows from your telematics providers and connected hardware through the Mative Cloud LM – Logistics Manager Ingest API, which normalizes and routes it to the relevant subsystems:

Mative Synapsis IoT
        │
        │  Push telemetry data
        ▼
Mative Cloud LM – Logistics Manager — Ingest API
        │
        ├─► DeviceEvent    (raw data point stored for history)
        ├─► Position       (driver/vehicle location update → live map)
        ├─► Sensor reading (temperature, humidity, door state, etc.)
        └─► Live map update (broadcast in real time)

Supported telematics providers

Mative Cloud LM – Logistics Manager integrates natively with the following telematics platforms:

Provider	Description
Flespi	Raw GPS and OBD-II data via MQTT and REST API
Geotab	Enterprise telematics with vehicle diagnostics
Samsara	Fleet operations platform with real-time GPS and video
Custom	Generic webhook/REST ingestion for any other provider

For custom integrations, Mative Cloud LM – Logistics Manager exposes a generic ingest endpoint that accepts standard telemetry payloads via HTTP POST or MQTT publish.

How it works in practice

1. A telematics modem is installed in the vehicle
2. The device sends GPS coordinates, speed, and OBD-II data to the provider's cloud
3. Mative Cloud LM – Logistics Manager connects to the provider using API credentials configured in the Connectivity settings
4. The provider streams data; vehicle positions are stored and broadcast to the live map in real time
5. Sensor readings are stored as DeviceEvent records; threshold violations surface as maintenance alerts

Benefits over LM Mobile app tracking

Mative Cloud LM – Logistics Manager supports two parallel tracking methods. For production fleets, both are typically used together — telematics for continuous vehicle data, and the LM Mobile app for driver workflow.

Feature	Telematics Device	LM Mobile App
Works without driver phone	✅	❌
OBD-II diagnostics	✅	❌
Battery / power monitoring	✅	❌
Sensor data (temp, door, etc.)	✅	❌
Tamper detection	✅	❌
Driver workflow (POD, navigation)	❌	✅

Tip

For most production fleets, both methods are used together — telematics for continuous hardware-level vehicle data, and the LM Mobile app for driver-side order management and proof of delivery.
